In this comprehensive tutorial, we walk you through the process of installing and configuring GNS3 on Proxmox using Linux Mint. Whether you’re setting up a network lab for learning or professional use, this step-by-step guide will help you get GNS3 up and running smoothly. We’ll cover the entire installation process, from setting up Proxmox as your virtualization platform to configuring Linux Mint and finally installing GNS3.
Commands used to transfer GNS3 into Proxmox
Transfer Command
scp ‘.GNS3 VM.ova’ root@IP Address:/tmp
Connect to Proxmox Server:
ssh root@IP Address
Change to the tmp directory:
cd /tmp
Show and list the contents in directory:
ls
Command to extract server files:
tar xvf “GNS3 VM.ova”
Now Import the GNS3 into a new VM
qm importovf 111 “GNS3 VM.ovf” data
Commands to install GUI on Linux Mint
sudo add-apt-repository ppa:gns3/ppa
sudo apt update
sudo apt install gns3-gui gns3-server
If you want IOU support
sudo dpkg –add-architecture i386
sudo apt update
sudo apt install gns3-iou
Read more about the documentation here:
